Our oil injection screw air compressor adopts multi-module design. Our domain expertise has enabled us to come with a remarkable best quality air compressor to our valued clients.
Our oil injection screw air compressor adopts multi-module design. Our domain expertise has enabled us to come with a remarkable best quality air compressor to our valued clients. According to your expected cost requirement, you can choose belt conveying type with low cost, direct connection type with low noise and highly efficient and energy saving frequency conversion type.
The air compressor adopts intelligent microcomputer controller. Coordinating with pressure, temperature, current and signal, it can provide 12 important indicator warnings and 13 omnibearing safety protection measures. Its other functions: Chinese and English display switchover and maintenance time limit reminder. RS485 communication interface realizes multi-machine joint control, which makes the customers learn about the condition concisely and roundly.
Air compressor application:
The air compressor is used in complete set of engineering production line, and is the air power source of the following equipments: color sorter, corn milling machine, packing machine, pulse dust collector.
|
Air Compressor |
|
||||||
|
Model |
Power |
Motor |
Gas Displacement |
Pressure |
Boundary Dimension |
Weight |
Outlet Size |
|
SCR5.5P - 7/8/10/12.5 |
4 |
5.5 |
0.65/0.6/0.5/0.4 |
7/8/10/12.5 |
1025*465*995 |
200 |
Rc 1/2 |
|
SCR7.5P - 7/8/10/12.5 |
5.5 |
7.5 |
0.85/0.8/0.7/0.6 |
7/8/10/12.5 |
1025*465*995 |
270 |
Rc 1/2 |
|
SCR10P - 7/8/10/12.5 |
7.5 |
10 |
1.1/1.0/0.9/0.8 |
7/8/10/12.5 |
1190*625*1215 |
270 |
Rc 1/2 |
|
SCR7.5M - 7/8/10/12.5 |
5.5 |
7.5 |
0.85/0.8/0.7/0.6 |
7/8/10/12.5 |
680*900*970 |
250 |
Rc 1/2 |
|
SCR10M - 7/8/10/12.5 |
7.5 |
10 |
1.1/1.0/0.95/0.85 |
7/8/10/12.5 |
680*900*970 |
250 |
Rc 1/2 |
|
SCR15M - 7/8/10/12.5 |
11 |
15 |
1.6/1.5/1.3/1.1 |
7/8/10/12.5 |
800*950*1130 |
380 |
Rc 3/4 |
|
SCR20M - 7/8/10/12.5 |
15 |
20 |
2.3/2.2/1.9/1.7 |
7/8/10/12.5 |
800*950*1130 |
420 |
Rc 3/4 |
|
SCR25M - 7/8/10/12.5 |
18.5 |
25 |
3.2/2.9/2.4/2.1 |
7/8/10/12.5 |
900*1150*1350 |
560 |
Rc 1 |
|
SCR30M - 7/8/10/12.5 |
22 |
30 |
3.8/3.5/3.2/2.9 |
7/8/10/12.5 |
900*1150*1350 |
580 |
Rc 1 |
|
SCR40M - 7/8/10/12.5 |
30 |
40 |
5.1/4.8/4.1/3.7 |
7/8/10/12.5 |
900*1150*1350 |
640 |
Rc 1 |
|
SCR50M - 7/8/10/12.5 |
37 |
50 |
6.4/6.1/5.7/5.1 |
7/8/10/12.5 |
1000*1300*1470 |
800 |
Rc1 1/2 |
|
SCR60M - 7/8/10/12.5 |
45 |
60 |
7.7/7.5/6.8/6.0 |
7/8/10/12.5 |
1000*1300*1470 |
920 |
Rc1 1/2 |
|
SCR75M - 7/8/10/12.5 |
55 |
75 |
10.4/9.4/8.4/7.8 |
7/8/10/12.5 |
1800*1450*1570 |
1540 |
Rc2 |
|
SCR100M - 7/8/10/12.5 |
75 |
100 |
13.8/12.9 /11.7/9.6 |
7/8/10/12.5 |
1800*1450*1570 |
1650 |
Rc2 |
